BOPP电容镀铝膜

BOPP电容镀铝膜 BOPP电容镀铝膜 BOPP电容镀铝膜 BOPP电容镀铝膜
产品名称:BOPP电容镀铝膜
产品编号:3919109900
详细说明:

BOPP(Polypropylene) capacitor film silver metallized Al or  Zn/Al safety and anti-explosion (explosion- protection )

  The capacitor of safety-film and the mechanism of explosion protection.

 Items:  BOPP capacitor film (clear and silver metallized) (3-12/15/18 Microns

------------------------------------------------------------------------------------------------

1. BOPP capacitor film -safety

1.) M-PP for metallized -film capacitors applications .

2.) S-PP for foil-film capacitors applications .

------------------------------------------------------------------------------------------------

2. BOPP capacitor film-rough(BOPP rough clear capacitor film)

1.) R-PP : one side of rough capacitor film (power capacitor use).

2.) RR-PP: two sides of rough capacitor film

------------------------------------------------------------------------------------------------

3. BOPP capacitor film silver metallized Zn/Al

------------------------------------------------------------------------------------------------------------------------

4. BOPP capacitor film silver metallized Al

------------------------------------------------------------------------------------------------

5.  BOPP capacitor film silver metallized Al or  Zn/Al safety and anti-explosion (explosion-proof )

------------------------------------------------------------------------------------------------

IMG_0291.jpgIMG_20140315_100914.jpgISO 90012008.jpgribbon jumbo rolls.jpg.jpg2 079.jpg

 Tips:   Certification: ISO9001, ISO14001, OHSMS18000

Each products have its own special,natural,outstanding soul!

One company (anhui eastern communication) offer  BOPP Metallized Capacitor Film (silver) products to the world market sufficiently.

Great largest market bone great largest enterprises, and great demand of  BOPP Metallized Capacitor Film (silver) all over the world pushs our company (anhui eastern communication) grewing largest scales.

Key data:   The standard thickness range including: 3 ,4,5,6,7,8,9,10,12 microns .

The standard tolerance thickness: +/-0.2 Um .

The width range including: can slit any width(MM )upon the requirement.

The inner core : 3" (76MM)  The outer core: 150-350 MM .


1. Base PP film for silver metallized PP capacitor film

Capacitor-used film: plated PP film's surface with a thin metal layer.

2.  metallized BOPP capacitor film

The high pure aluminum or zinc melting, in under high vacuum evaporation, precipitation to the surface base film, plastic film is formed a thin layer of metal layer after membrane surface.

3. self-healing ,  self-healing function of self-healing

Metallized film dielectric after local breakdown immediately instinctively to the electrical properties of the phenomenon of breakdown before.

4. margin,  left side margin

The need for the actual production of capacitors, metallized film on one side or both sides of the edge or middle cover form without steaming blank metallized insulation strip (strip) called the edge, its width is called the margin.

5. square resistance, The sheet resistance of square resistance

The metal layer of metal film on the unit square area of the resistance value is called the square resistance, expressed by Omega /, usually with square resistance to represent the thickness of the metal coating.

6. metallized safe film, metallic safety film metallized safety film

The metal pattern layer containing metal film fuse safety structure. According to the structural characteristics of fuse safety can be divided into grid security film, security film and T series safety film etc..

Classification: types of products

MPPA(MPETA) -- single aluminum metallized polypropylene film (or polyester) shown in Figure 1, figure 3.Figure 1 Figure 2 Figure 3

MPPAD (MPETAD) -- double aluminum metallized polypropylene film (or polyester), see Figure 4 and figure 5.

MPPAH (MPETAH) -- single aluminum metallized polypropylene edge thickened metal layer (or polyester) film, see figure 6.

MPPAZ (MPETAZ) -- a single zinc aluminum metallized polypropylene film (or polyester), see figure 7

MPPAZHX (MPETAZHX) -- a single zinc aluminum metallized polypropylene edge thickened metal layer (or polyester) BT composite mesh type safety film, see figure 8.

MPPAT (MPETAT) -- single aluminum metallized polypropylene (or polyester) T type safety film, see figure 9.

The code in the:   M said the metallization;

PP said polypropylene film;

PET said polyester film;

A metal coating for aluminum;

AZ metal coating is zinc aluminium composite;

D said the double-sided metallization;

H said edge thickened metal layer;

X said the grid security film;

T said T safety film.

2 edge type    1 classification margin products and edge character code

S -- edge on one side of the membrane, see Figure 1, figure 4, Figure 6 and figure 7;

T -- the edges at both sides of the membrane, see figure 2;

M -- margin in the middle of the film, see figure 3.

2 no margin products without edge character code, see figure 5.

3 specifications    Metallized film specifications expressed in three section of the Arabia digital, the first section number indicates the nominal thickness of metal film (m), second digital representations of metallized film width (mm), third digital representation of metallized films margin (mm), multiplication in each section numbers (x) connected.

Example: 8 x 75 x 2.5 metal film thickness of 8 μ m, width of 75mm, margin for 2.5mm

4 model      Product by product type, edge type and specification of three parts.

Specification Edge type  Product types   Figure 10 model example

5 model example:  Cases of 1:MPETA - S - 6 * 8 * 2-----The thickness of 6 μ m, width of 8mm, margin for 2mm, edge on one side of the membrane of single aluminum metallized polyester film

Cases of 2:MPPAZH - S - 6 * 10 * 1.5-----The thickness of 6 μ m, width of 10mm, margin for 1.5mm, left side of Zn Al composite metal single edge thickened metallized layer on one side of the membrane of the polypropylene film

Patients with 3:MPETAD 6 * 35-----The thickness of 6 μ m, width of 35mm, no left side of the double-sided aluminum metallized polyester film

Cases of 4:MPPAZX - S - 6 * 8 * 2-------The thickness of 6 μ m, width of 8mm, margin is 2mm, one side edge of Zn Al composite metal on one side of the membrane of the polypropylene mesh type safety film

Though more then ten years research in the developed countries, safety film for capacitors of explosion protection has come into the large-scale production.

Its unique inner net-shaped structure is a new explosion protection mode.

 Specification for Metallized poIyester film and poIypropyIene film for capacitors


2. Usage:  It was widely used for AC motor capacitors and other electronic parts

3. Packing: carton and pallets (use cartons and kraft paper and bobble film to packing as inner package, and use pallets and wood board to packing as outer package)
