| Bopp Thermal lamination Films |
|
Environmentally friendly:It is environmentally friendly,nonhazardous to healty and safe to use no toxic gases or voatile content is emitted.Safety in laminating process ad no solvent based adhesive is used.
High function:Compared with other solvent lamination,our film is better in clarity and bonding.Strong ability of absorbing power.It prevents lamination from being pressed,bubbled and shredded off easily.Matt thermal lamination film is good for spot UVand hot stamping.
Easy handing:It is easy to operate once the required temperatures is met and no special technique required.
Effcient and energry-saving:Production costs it reduced substantially ad there is no film wastage,mixture of adhesive solvent,and ni UV heating lamp is required.
Adaptable to diffeerent kinds of machines:This film is recommended to be used in dry laminator.Small adjustments need to be made to the machine if the film is used in wet laminator.
SPECIFICATION&PARAMENTER
| SPECIFICATION |
GLOSS |
GLOSS |
GLOSS |
GLOSS |
MATT |
MATT |
MATT |
| THICKNESS |
TOTAL |
24 |
25 |
27 |
29 |
26 |
28 |
30 |
| BASE |
12 |
15 |
17 |
17 |
15 |
17 |
18 |
| ADHESIVE |
12 |
10 |
10 |
12 |
11 |
11 |
12 |
| WIDTH(MM) |
360 390 440 540 590 780 880 1080 1320 (or as per cuestomer’s request) |
| LENGTH(M |
MAX:5000 |
| PAPER CORE |
25.4MM(1 inch) 58MM(2 ubcg) 76MM(3 inch) MD:2.4*106 dyne/cm
|
| TENSILE |
MD:2.4*106 dyne/cm CD:5.3*106 dyne/cn |
Process Requirement:
Equipment for laminating film:dry and wet film laminartor.
Temperature:Normal:85-100℃ Special:100-110℃
Roller pressure:10-18Mpa
Speed:8-20m/min
Remarks:Special laminatioins refer to those with thicker ink,solid color,high moisture content and bigger size paper.
Application manual:
1.Adjust roller pressure and temperature according to different types of paper and ink.
2.When using the film for the first time or changing to other sizes,we recommend a small trial volume before going into fully mass lamination.
3.The following situation will affect quality of the film during lamination.
a.When using metal ink
b.When the ink contains too much max,dried oil,adhesive,and silicon additive,etc
c.When the ink is too thick
d.When the ink is not completely dry
e.When the paper contains too much moisture
f.When there is too much power.
|
Spec.: 1.) Jumbo roll sizes:
Total Thickness: 20-33UM (Mic.) ,such as: 18,20,22,25,28,30,32,35 microns
Basic film thickness: 10,12,15,18,20 UM (Mic.) Width :325-1200MM
Length:3000M (2000M,2500M,4000M).Inner core:76MM ,152MM
2.) Mini-roll sizes (Inner core: 1",1.5", 2.0"): Total Thickness :20-33UM
(Mic.) Film thickness: 10,12,15,18,20 UM (Mic.) Width :325-1200MM
Type:included BOPET thermal film (Polyester thermal lamination film with EVA),BOPA thermal film (nylon
thermal lamination film with EVA), bopp thermal film (Polypropylene thermal lamination film with EVA)
Length :100M,120M,150M,200M Inner core :1.5",1.8", 2.0",3" (Inches)
3.) SOFT VELVET BOPP THERMAL LAMINATING FILM, THICKNESS: 30MIC. (17MIC LASER BOPP 13 MIC EVA)
a. Laser BOPP thermal ( opaque,non-transparent),thickness: 20Mic. (12Mic BOPP laser+8Mic EVA)
b. Laser BOPP thermal ( clear/transparent),thickness: 28Mic. (18Mic BOPP laser+10Mic EVA)
c. Soft-Velvet Bopp thermal ,thickness: 30Mic.(17Mic BOPP laser+13Mic EVA)
d. Laser BOPP thermal normal
Applications:Laminate the surface of Books, catalogs, samples, posters, printed paper, Food, medicines, cosmetics, gifts, wine boxes and other packaging film ,Drawings, documents, ads, pictures, display boards, etc.
BOPP/BOPET/MPP/MPET THERMAL LAMINATING FILM, BOPP or PET base film and EVA adhesive, used in Printed matter (Books, magazines, leaflet, poster, etc.), Packaging (Crates or boxes for liquor, food, beverage, medicine, cosmetics and other daily consumer products, etc.) & Digital printing: (Photos, documents, billboards, etc.).
