Description of Products:
Featured by non—toxic,pollution—free,high transparency and gloss,low static,wear resistance,long ageing of corona,few defects and good opening,this product is mainly used for the composition of printing,bag making,adhesive tape production and other base materials It is widely used for clean and dust—free workshop in the areas of clothing and foodstuff packaging
It is provided with strong powder absorption and can blister and film release after being concaved or protruded Matte lamination film is also suitable for partially UV glazing after film laminating,thermo printing,screen printing and frosted processes
This prodct is easy to operate Once the temperature of hot roller meets the requirements,film laminating can be done at any time,with no need of professional skill.
Operation Parameters:
Film laminating equipment:dry or wet type film laminator
Temperature of hot roller:General printing materials:85~100°C
Special printing materials:100~110°C
Pressure:10~18Mpa
Speed:8~50m/min
Film specification
|
Specification
|
BOPP-20glossy
|
BOPP-25glossy
|
BOPP-27glossy
|
BOPP-23matte
|
BOPP-27matte
|
BOPP-30matte
|
|
Thickness(∪)
|
Total
|
20
|
25
|
27
|
23
|
27
|
30
|
|
BOPP
|
12
|
12
|
15
|
15
|
15
|
18
|
|
EVA
|
8
|
13
|
12
|
8
|
12
|
12
|
|
Weight
|
M2/kg
|
54.6
|
43.22
|
40.1
|
47.03
|
41.35
|
37.37
|
|
g/m2
|
18.36
|
23.1
|
25
|
21.26
|
24.18
|
26.76
|
|
Width
|
200 390 440 540 590 780 880 1330 1900 ±3mm
Upon customer’s desire
|
|
Length
|
2000,3000 M ±5%
|
|
Paper core
|
Inside paper core 25.4mm 50.8mm 63.5mm 76mm
|
Spec.: 1.) Jumbo roll sizes:
Total Thickness: 20-33UM (Mic.) ,such as: 18,20,22,25,28,30,32,35 microns
Basic film thickness: 10,12,15,18,20 UM (Mic.) Width :325-1200MM
Length:3000M (2000M,2500M,4000M).Inner core:76MM ,152MM
2.) Mini-roll sizes (Inner core: 1",1.5", 2.0"): Total Thickness :20-33UM
(Mic.) Film thickness: 10,12,15,18,20 UM (Mic.) Width :325-1200MM
Type:included BOPET thermal film (Polyester thermal lamination film with EVA),BOPA thermal film (nylon
thermal lamination film with EVA), bopp thermal film (Polypropylene thermal lamination film with EVA)
Length :100M,120M,150M,200M Inner core :1.5",1.8", 2.0",3" (Inches)
3.) SOFT VELVET BOPP THERMAL LAMINATING FILM, THICKNESS: 30MIC. (17MIC LASER BOPP 13 MIC EVA)
a. Laser BOPP thermal ( opaque,non-transparent),thickness: 20Mic. (12Mic BOPP laser+8Mic EVA)
b. Laser BOPP thermal ( clear/transparent),thickness: 28Mic. (18Mic BOPP laser+10Mic EVA)
c. Soft-Velvet Bopp thermal ,thickness: 30Mic.(17Mic BOPP laser+13Mic EVA)
d. Laser BOPP thermal normal
Applications:Laminate the surface of Books, catalogs, samples, posters, printed paper, Food, medicines, cosmetics, gifts, wine boxes and other packaging film ,Drawings, documents, ads, pictures, display boards, etc.
BOPP/BOPET/MPP/MPET THERMAL LAMINATING FILM, BOPP or PET base film and EVA adhesive, used in Printed matter (Books, magazines, leaflet, poster, etc.), Packaging (Crates or boxes for liquor, food, beverage, medicine, cosmetics and other daily consumer products, etc.) & Digital printing: (Photos, documents, billboards, etc.).
Technology data
