Digital Thermal Laminating Film (Gloss & Matt)
*Material
Surface layer: BOPP
Glue layer: EVA adhesive
*Specification
Thickness: 20-35Mic
*Material
Surface layer: BOPP
Glue layer: EVA adhesive
*Specification
Thickness: 20-35mic
Width: 300~1800mm
Length: 200~3000m
Paper core: 25.4mm (1 inch), 58mm(2.25inches), 76mm(3 inches)
Bonding: Less than 2
*process parameter:
Equipment for thermal film: Dry and wet film laminator
Lamination temperature: 95~105c
Roller pressure: 10-20mpa
Speed: 8-20 m/min
*directions for using BOPP thermal laminating film:
Normal process temperature is 90c-105c, roller pressure and temperature vary with different types of paper, ink and machines.
When using the film for the first time or do other treatment, try a small volume before mass laminating.
Make sure the ink is dry before laminating. It will delaminate when the paper contains too much moisture and powder.
Make sure put the material in a low-temperature, dry place. 35mic
Width: 300~1800mm
Length: 200~3000m
Paper core: 25.4mm (1 inch), 58mm(2.25inches), 76mm(3 inches)
Bonding: Less than 2
*process parameter:
Equipment for thermal film: Dry and wet film laminator
Lamination temperature: 95~105c
Roller pressure: 10-20mpa
Speed: 8-20 m/min
*directions for using BOPP thermal laminating film:
Normal process temperature is 90c-105c, roller pressure and temperature vary with different types of paper, ink and machines.
When using the film for the first time or do other treatment, try a small volume before mass laminating.
Make sure the ink is dry before laminating. It will delaminate when the paper contains too much moisture and powder.
Make sure put the material in a low-temperature, dry place.
Spec.: 1.) Jumbo roll sizes:
Total Thickness: 20-33UM (Mic.) ,such as: 18,20,22,25,28,30,32,35 microns
Basic film thickness: 10,12,15,18,20 UM (Mic.) Width :325-1200MM
Length:3000M (2000M,2500M,4000M).Inner core:76MM ,152MM
2.) Mini-roll sizes (Inner core: 1",1.5", 2.0"): Total Thickness :20-33UM
(Mic.) Film thickness: 10,12,15,18,20 UM (Mic.) Width :325-1200MM
Length :100M,120M,150M,200M Inner core :1.5",1.8", 2.0",3" (Inches)
3.) SOFT VELVET BOPP THERMAL LAMINATING FILM, THICKNESS: 30MIC. (17MIC LASER BOPP 13 MIC EVA)
a. Laser BOPP thermal ( opaque,non-transparent),thickness: 20Mic. (12Mic BOPP laser+8Mic EVA)
b. Laser BOPP thermal ( clear/transparent),thickness: 28Mic. (18Mic BOPP laser+10Mic EVA)
c. Soft-Velvet Bopp thermal ,thickness: 30Mic.(17Mic BOPP laser+13Mic EVA)
d. Laser BOPP thermal normal
Applications:Laminate the surface of Books, catalogs, samples, posters, printed paper, Food, medicines, cosmetics, gifts, wine boxes and other packaging film ,Drawings, documents, ads, pictures, display boards, etc.
