产品展示

BOPP 烟膜

BOPP 烟膜 BOPP 烟膜 BOPP 烟膜 BOPP 烟膜
产品名称:BOPP 烟膜
产品编号:3919109900
详细说明:
 High shrinkage BOPP tobacco cigarette packets wrapping film

Shrinkage : 8-10%

size:

Size: 22Microns*105mm*2800M

22Microns*110mm*2800M

22Microns*115mm*2800M

22Microns*118mm*2800M

22Microns*120mm*2800M

22Microns*125mm*2800M

22Microns*130mm*2800M

22Microns*135mm*2800M

22Microns*225mm*2800M

22Microns*350mm*2800M

22Microns*380mm*2800M

22Microns*420mm*2800M

 High-shrinkage BOPP Cigarette Film with heat sealable matches high-speed packaging machines.

3.) Specific property

Unit   Typical numerical value  Testing Standard Grade AEC21 Grade AEC22 Corporate National  International
 Density g/cm3 0.905 0.905 ASTM D1505
Thickness μm 21 22 Q/SD2 GB/T6672-2001
Unit weight g/m2 19.0 19.9
Yield m2/kg 52.6 50.3
Tensile strength MD N/mm2 160 150 Q/SD2 GB/T1040-1992 ASTM D882  TD 287 280
Elongation at break MD % 172 180 Q/SD2 GB/T1040-1992 ASTM D882 TD 63 60
Heat shrinkage MD % 3.5 3.2 Q/SD2 GB/T12026-2000 ASTM D1204-89 TD 2.8 2.5
Young’s modulus MD N/mm2 2200 1980 Q/SD2 ASTM D882  TD 3900 3300
Heat sealing strength N/15mm 2.6 2.7 Q/SD2 QB/T2358-1998 ASTM F88-94
Temperature range of heat sealing °C 120~150 120~150 Q/SD2 QB/T2358-1998 ASTM F88-94
Friction co-efficient 0.20 0.20 Q/SD2 GB/T10006-1988 ASTM D1894-93
Haze % 1.3 1.5 Q/SD2 GB2410-1980 ASTM D1003-95
(45°) Gloss % 85.0 85.0 Q/SD2 GB8807-1988 ASTM D2457

 DSC04099_.jpgDSC04103.JPGsample photo 1.jpgsample photo 3.jpgsample photo 4.jpgsample photo 8.jpg20130225_143116.jpgQQ20140612140742.jpgQQ20140612150412.jpg



 2. Usage

It is widely used in packaging soft and hard tobacco cigarette packets

3. acking: Use carton and kraft paper and bobble film to packing as inner package, and use pallets and wood board to packing as outer package

4. Featuring :

Super high transparency and glossy,Super high tensile strength
Super high grease barrier, Excellent ink and coating adhesion
Low static electricity,Superior thickness uniformity
Smoothness of the vertical section and much compact of film rolls winding

4. Technology data:
TYPICAL VALUES AND PHYSICAL PROPERTIES

Specification of Polypropylene film (PP Film)
Size: 100 mm. * 3,600 m.
Size: 115 mm. * 3,600 m.
Size: 122 mm. * 3,600 m.
1. Type Biaxially Oriented Polypropylene,
Maximum temperature seal does not over than 180 °C
2. Core Inside diameter of core 76mm., Thickness of core 8mm.
The length as width of PP Film
3. Thickness 0.018 – 0.024 mm.
4. Basis Weight 16 – 22 gms./ m²
5. Stiffness Not less than 11mm.
6. Heat – Seal Strength Not less than 300gms
7. Water Vapour Permeability Not over than 10gms/m²/24hours
8. Blocking Resistance Not tightly sealed at a pressure of 35 gms/m²
Period of 24 hours at 40°C, Humidity 40%
9. Odour Odourless
10. Haze Not over than 2.2%
11. Gloss : 45° Not less than 75%
12. General Appearance Tightly rol l
Incision is flat at both sides.
Seamless in the roll. If ne cessary the joints do not exceed
one mark per roll, But not over than 10% of each delivery.
By mark cleanly.
PS. the seller must specify the temperature when use

5. Standar Dimentions
