BOPP 薄膜

BOPP 薄膜
产品名称:BOPP 薄膜
产品编号:3919109900
详细说明:


IMG_20150113_115530.jpgIMG_20150113_115908.jpgIMG_20150113_120051.jpgQQ20150116085744.jpgQQ20150116091207.jpgQQ20150116091238.jpg



Super clear and glossy  BOPP film (Polypropylene film)

with

a.) one side corona treatment



b.) both side(s) corona treated.



    1. Stype:

Specifications

 Thickness:15,18,20,25,30,35,40 micron Width:350-1600 mm

Length:1000m,2000M,4000m ,6000m ,7000m, 8000m

For example:

a.)

BOPP smaller rolls for gift flower wrapping in clear and color logo printed:

25Mic*900MM*200M

 b.)



BOPP smaller rolls for packet/box wrapping :



20Mic*118,120,125,130,135,150,350,380MM*6000M











Color: Transparent(clear) or printed logos.
Packing: use carton & pallets or as customers requirements
Customer's own requirement is available for us such as printed OEM logos and private label or particular size and package style.



 IMG_20150113_110023.jpgIMG_20150113_110028.jpgIMG_20150113_110036.jpgIMG_20150113_110041.jpgIMG_20150113_110046.jpgIMG_20150113_110053.jpg



2. Usage:  It is widely used in packaging industry such as printing, lamination and Aluminium metallization.



3. Featuring :



Super high transparency and glossy,Super high tensile strength
Super high grease barrier, Excellent ink and coating adhesion
Low static electricity,Superior thickness uniformity
Smoothness of the vertical section and much compact of film rolls winding







4. Technology data:
TYPICAL VALUES AND PHYSICAL PROPERTIES

PROPERTY TEST METHOD THICKNESS UM
UNIT 15 20 25 30 35 40
OPACITY % ASTM D 1003 1.5 1.8 2.2
BRIGHT @ 45º % ASTM D 2457 80
COEFFICIENT OF FRICTION TO/TO ¨¨¨¨¨¨ ASTM D 1894 0.20
T/T 0.35 0.25
TENSILE STRENGTH MD N/mm2 ASTM D 882 125
TD 235
ELONGATION AT BREAK TD % 180
MD 50
DRYING MODULE @ 2% MD N/mm2 1.700
TD 3.000
CORONA TREATMENT dinas/cm ASTM 2578 38
SEALING TEMPERATURE TN ºc ASTMF88/ 105
T 125
SEALING STRENGTH TN N/25mm 4.0 5.0
T 3.5 5.5
WATER VAPOR TRANSMISSION g/m2/dia ASTM F 1249 8.5 6.5 5.6 4.7 4.3 3.8
@ 38ºC,90% HR
OXYGEN TRANSMISSION g/m2/dia ASTM D 3985 2,900 2,200 1,800 1,600 1,400 1,200
@ 22ºC,0% HR

NOTE :

MD MACHINE DIRECTION
DT TRANSVERSE DIRECTION
OT FACE NOT TREATMENT
T TREATMENT

the data in this data sheet should be used as guide values and not as specification limits







5. Standar Dimentions
Thickness (um) Weight (g/m2) Wide (mm) center carton 550mm External Diameter 760mm External Diameter
length(m) weight(Kg/cm) length(m) weight(Kg/cm) Treated side
15 13.6 13.900 27.800
17.5 15.8 11.900 23.800
20 18.1 400 10.300 20.600
25 22.6 to 3” to 6” 8.250 1.89 16.500 3.77 External
30 27.2 2000 6.900 13.800
35 31.7 5.900 11.800
40 36.2 5.150 10.300
50 45.3 4.150 8.300
